24" x 24" Galvanized Security Roof Hatch
Application
Best Access Doors BA-RHG-SEC designed to provide convenient, economical access to the roof of a building while adding an additional level of security. The heavy gauge materials used to manufacture this hatch are ideal for applications in banks, prisons, hospitals, and more.
- Weather tight construction
- Convenient one-hand operation
- 12" high insulated curb Supports
- 40lbs./sq. ft. live load
Features BA-RHG-SEC
Cover: Double-skin construction (“in box type design”) with 1" cellulose insulation and a continuous EPDM foam weather/draft seal gasket that is attached to the inside of cover to provide a flush, tight fit. Designed to support a liveload of 40lbs./sq. ft.,
Curb: 10 gauge galvanized steel with 1" thick fiberboard roof insulation at curb exterior. Curb is 12" high, with 3.375" wide bottom flange and pre-drilled mounting holes.
Hinge: Heavy duty galvanized steel pintle hinges with 3/8" pin
Opening: Gas spring operators allow cover to open and close with ease. Inside pull handle allows for easy control when closing cover.
Door Latch: Self latching, zinc plated outside T handle with stainless steel inside lock and lever assembly. Heavy duty detention lock with paracentric key. Unit also has inside and outside padlock provisions.
Finish: Material is prepared with an iron phosphate wash, followed by a rust inhibiting primer, and then a baked on polyester enamel paint.
Optional Features BA-RHG-SEC
- Stainless Steel cover, curb, and/or hardware
- Aluminum Material
- Louvered Curbs
- Curb Mounted Units
- Curb pitch corrected for sloped roof
- Higher curb heights for "green roof" applications
